0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W

0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W
0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W 0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W 0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W 0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W

Large Image :  0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W

Product Details:
Place of Origin: China
Brand Name: QTC
Certification: ISO
Model Number: P600
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: export packing
Delivery Time: 10-15 days
Payment Terms: Western Union, MoneyGram, T/T
Supply Ability: 500 sets / month
Contact Now

0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W

Description
Mode Of Operation: Continuous Wave Products Handled: Sheet Metal
Laser Type: Fiber Laser Axis: 3-axis
Cutting Thickness: 0.2mm-5mm Cutting Area: 600mm*600mm
Highlight:

5mm Metal Sheet Laser Cutting Machine

,

0.2mm Metal Sheet Laser Cutting Machine

,

Laser Cutting Machine 2000W 3000W

High Precision Metal Fiber Laser Cutting Machine For Cutting 0.2-5mm Metal Sheet



High-precision fiber laser cutter is designed for cutting thin metal sheets (0.2mm-5mm). An open motion control platform integrating motion control, PLC, and HMI, with a high-strength marble platform to ensure high-precision cutting equipment.

0.2mm-5mm Metal Sheet Laser Cutting Machine 2000W 3000W 4000W 0



Item Parameter
1500W
Processing format (length * width) 600*600mm
Laser Power 1kW-6kW
X-axis travel 600mm
Y-axis travel 600mm
Z-axis travel 100mm
X/Y axis positioning accuracy ±0.02mm
Repeated positioning accuracy of X/Y axis ±0.005mm
Total power ≤3000W
Total Weight About 1.4T
Size 1800*1430*1800mm



  • The frame adopts marble structure, which has good overall rigidity and high strength; the beam body adopts lightweight design, which has good acceleration performance, and is precisely processed by CNC gantry milling machine to ensure accurate movement.
  • The equipment adopts extruded aluminum profiles for beams, which can effectively prevent structural deformation.
  • The EtherCAT bus-based CNC system (AheadTechs) greatly improves the flexibility and scalability of the equipment. Make smart factories and equipment interconnection possible.
